Storage Case PBQD2

The metric torque instrument PBQD2 belongs to the Snap-on metric click-type torque wrenches (kg·m, kg·cm) range, and Lost in HCM supplies it to workshops and factories across Vietnam. Snap-on lists the country of origin as CHN.

Metric torque instrument PBQD2 overview

Teams that work on machines with kilogram torque specs need a wrench that reads the same way. The metric torque instrument PBQD2 gives you that match, with a laser etched scale that stays easy to read. In short, you set the value you see in the manual.

Each wrench is calibrated at the factory on a standard traceable to NIST. In addition, the low-friction Hour Glass cam helps the click stay consistent. Lost in HCM supplies these tools with CO/CQ papers, a VAT e-invoice, and a valid calibration certificate.

Specifications at a glance

The table below follows the Snap-on data for PBQD2. In addition, we converted imperial torque values to N·m where Snap-on lists none.

How the metric torque instrument works

A click-type torque wrench holds a spring that presses a cam against a pivot block. You turn the handle to set the spring force for your value. Then, when you pull to that torque, the block trips past the cam and the wrench clicks.

Snap-on uses an Hour Glass cam shape in these wrenches. The shape cuts the contact area between the cam and the tube wall. Because of this, friction stays low, so the click point repeats more closely from one pull to the next.

Key features of the metric torque instrument PBQD2

Both wrenches in this family share the same design logic, from the kilogram scale to the sealed ratchet head. Here are the features that matter most when you compare options.

• Kilogram torque scales. The wrenches read directly in kg·cm or kg·m. Therefore, teams can set values straight from manuals that list kilogram specs, without a conversion table on the bench.
• Two drive sizes and ranges. The 3/8 inch model covers 200 to 1,000 kg·cm, while the 1/2 inch model covers 6 to 30 kg·m. So the pair spans light covers up to heavy chassis bolts.
• Sealed 80-tooth ratchet head. Both wrenches use a sealed ratchet head with 80 teeth. The seal keeps out dirt and moisture, so the head stays nearly maintenance free in daily use.
• Short 4.5 degree swing arc. The 80-tooth gear needs only a 4.5° swing to catch the next tooth. As a result, the wrench keeps working in tight spaces with little handle travel.
• Hour Glass cam design. The low-friction Hour Glass cam reduces contact between the cam and the tube wall. In addition, lower friction helps the click point stay steady over many cycles.
• Published accuracy rating. The wrenches list ±4% accuracy clockwise and ±6% counterclockwise from 20 to 100% of full scale. That rating meets the ASME accuracy that Snap-on certifies at the factory.

Snap-on data sheet notes

Snap-on also lists these details for PBQD2:

• Fits QD21000, QD2R1000, QD275, QD2FR75, QD2100, QD2R100A, QD2RM1000, QD2RN25A, QD2RN50 and QD2RN100 torque wrenches.

Typical applications

These wrenches solve one clear problem: setting kilogram torque specs without conversion. Below are typical jobs where that matters, from motorbike engines to machine tools. Each one also rewards a known torque value.

• Japanese and Korean vehicle service. Older Japanese and Korean service manuals often list torque in kg·m. Therefore, a kilogram-scale wrench lets technicians set each value directly from the page.
• Motorbike engine and chassis work. Motorbike engines and frames use many small and medium bolts with kilogram specs. The 3/8 inch model in kg·cm suits covers and mounts, while the 1/2 inch model handles axles.
• Machine tool maintenance. Many Asian machine tools ship with manuals that list kgf values for clamps and mounts. So maintenance teams can match those specs without risk of a unit mistake.
• Wheel and suspension bolts. Wheel nuts and suspension bolts on many vehicles fall within the 6 to 30 kg·m range. In addition, the sealed ratchet keeps road grit out during tire shop use.
• Training in metric units. Trainees often learn torque in N·m but meet kg·m in older manuals. With a kilogram-scale wrench, instructors can show both units side by side and explain the link.
• Spare tool for mixed fleets. Fleets that run older and newer vehicles see both N·m and kg·m specs. For example, keeping one kilogram-scale wrench nearby avoids quick mental conversions under time pressure.

Industries that use the metric torque instrument PBQD2

Any sector that services older Asian machines or vehicles gains from a wrench that reads in kilogram units. So these tools show up in workshops, plants, and training rooms. Here is how each industry uses them.

• Automotive service. Dealers and workshops in Vietnam service many Japanese and Korean models with kilogram specs in older manuals. So a kilogram-scale wrench helps them hit each value and pass FDI fleet audits.
• Motorbike service and assembly. Vietnam has one of the largest motorbike markets in Asia, with many Japanese brands. Therefore, workshops and assembly plants often meet kg·cm and kg·m specs in daily work.
• Machine tool maintenance. Plants in Binh Duong and Dong Nai run Japanese and Taiwanese machine tools with kgf specs. Maintenance teams also need calibrated tools that leave a clear record for audits.
• Heavy equipment maintenance. Older excavators, loaders, and forklifts from Asian makers often list torque in kg·m. For this reason, service contractors across Vietnam keep kilogram-scale wrenches in their kits.
• Electronics and electrical. Electronics plants in Bac Ninh use Asian assembly machines with kg·cm settings. In addition, small brackets and mounts on these machines suit the 3/8 inch kg·cm model.
• Technical training centers. Vocational schools and plant training rooms teach both modern and older torque units. Meanwhile, a kilogram-scale wrench helps trainees read real manuals they will meet on the job.

Metric torque instrument PBQD2 compared with similar brands

Before you buy, compare the metric torque instrument PBQD2 with other metric click wrenches your team may use. The key question is the unit on the scale. After that, compare drive size, ratchet design, and service support in Vietnam.

If your manuals list kilogram torque, these Snap-on wrenches remove a conversion step and its errors. They also share cases and service kits with other QD models. Even so, confirm current specs with each maker before you compare units and ranges. Specifications change over time, so confirm current data with each maker before you decide.

Choosing the right model

• Start with the unit in your service manual. If it lists kg·cm, the 3/8 inch model fits, while kg·m specs suit the 1/2 inch model.
• Pick a range that puts your torque spec in the middle of the scale. Accuracy holds from 20 to 100% of full scale, so avoid the bottom end.
• Check the drive size against your sockets. For example, the 3/8 inch model suits small and medium bolts, while the 1/2 inch model handles heavier work.
• Order the matching case with each wrench. The PBQD2 fits the 3/8 inch model, and the PBQD3 fits the 1/2 inch model and other QD3 wrenches.
• Plan for N·m jobs as well. If your team also uses N·m specs, keep a separate dual-scale wrench instead of converting on the shop floor.
• Read the warranty line on each product page. The wrenches carry a one-year Snap-on Repair Center term, while the cases list a vendor warranty.

For other sizes in the same range, compare Storage Case PBQD3, 1/2" Drive Metric Adjustable Click-Type Fixed Ratchet Torque Wrench (6-30 kg•m) – QD3RM30A, 3/8" Drive Metric Adjustable Click-Type Fixed Ratchet Torque Wrench (200–1,000 kg•cm) – QD2RM1000A. Also browse the full Snap-on torque tools shop for handles, testers and adapters.

Care, storage and calibration

• Store the wrench in its case at the lowest scale setting. Then the spring rests between jobs, which helps the click point stay true.
• Wipe the wrench with a dry cloth after use, and never dip it in solvent. Also keep the scale clean, because grime can hide the markings.
• Send the wrench for calibration every 12 months or 5,000 cycles, as ISO 6789-1:2017 recommends. We can arrange recalibration through an accredited laboratory.
• Never pull past the click or use the wrench as a breaker bar. Overload can shift the setting, so check it against a tester after any hard hit.
• Carry the wrench in its PBQD2 or PBQD3 case between sites. In addition, keep it dry during the humid season so the ratchet and scale stay clean.

Frequently asked questions

Request a quote

Send us the part number, quantity and delivery site, and we will reply with a quote. You can request a quote online or call 0902 327 669.
